Description
Tunable Color Temperatures
3500K
4000K
5000K
ETH-TT2VT4-40/50/60W-3CCT
TriLum Tunable™ LED Vapor Tight, 4-FT, 60W Max, 3-Wattages + 3-CCT (35/40/50K), Wet Rated, 135 lm/W, Dimmable + Smart AUX Input
Applications
Premium indoor luminaire for hanging or surface mounting in ceiling spaces less than 25 feet. Suitable for gymnasiums, warehouses, manufacturing, packaging, storage, aisles, work-stations, and covered decks.
Construction
Manufactured for durability with injection molded polycarbonate to resist corrosion, discoloration, and scratching. Stainless steel clips lock the lens cover to resist dust, moisture and vapors. Wet Location rated.
Electrical
Input voltages 120-277V models with 0-10V Continuous Dimming. Tunable 3-CCT (3500K, 4000K, 5000K) and Tunable 3-Wattages. Operating temperatures -4°F to 104°F (-20°C to 40°C).
Mounting
Aluminum Surface Mount Clips standard.
Optics
Anti-UV Frosted Polycarbonate Lens standard.
Controls
Installed fixture mounted Microwave Sensor, PIR Sensor or Bluetooth with Daylight Priority available. Remote Control available.
Emergency
Installed 90 Minute Emergency Backup Battery LED Driver available.
Listings
DLC Premium listed. UL certified to meet US and Canadian standards. FCC and RoHS compliant.
Warranty
7 year exclusive limited warranty.
Download Spec Sheet | More Data
Additional information
| Energy Data | Input Frequency: 50/60 Hz Input Voltage: 120-277V Operating Temperature: -4°F to 104°F (-20°C to 40°C) Power Factor: >0.9 THD: <10% Wattage: 3-Wattages (40W, 50W, 60W) |
|---|---|
| Lighting Data | Lumens: (5400, 6750, 8100) CCT: 3-CCT Select, 3500K, 4000K, 5000K CRI: ≥80 Dimmable: 0-10V Efficacy: 135 lm/W L70: 75000 hrs |
| Physical Data | Color: Gray Semi-Gloss Diffuser: Frosted Lens Type: Polycarbonate Size: 4-FT Rating: Wet Location Warranty: 7 Years |
Model variations…
TriLum Tunable™ LED Vapor Tight, 8-FT, 90W Max, 3-Wattages + 3-CCT (35/40/50K), Wet Rated, 135 lm/W, Dimmable + Smart AUX Input
